TOPNET NL-32 Automatic Level
Short info :
An auto level, also known as an automatic level or dumpy level, is a surveying instrument used to establish or verify points in the same horizontal plane. It's a key tool in construction and civil engineering for tasks like setting foundations, measuring subsidence, and building fences, ensuring accurate height measurements and leveling
Wizard Auto 250 KN - Automatic Compression Testing Machines
Description:
An auto level is a tool that’s being used by contractors, builders, land surveyors, and engineers so they can get consistent leveling every single time. It’s easy to use and can be set up quickly, which can save both time and money. Engineer Supply has a variety of automatic levels from some of the best manufacturers in the industry, so feel free to take a look at what we have in stock.
Features:
Features
- Equipped with advanced Magnetic-damping
- Compensation system (V-type suspension wire)
- Optical peep sight or gun sight optional
- Super clear imaging system and Hermetically-sealed structure for all weathers.
- Color optional: Green & Yellow
Standards:
Automatic Level AT-32 (TOPNET MAKE)
Having 32x Magnification, Accuracy ±2mm Image Erect, Effective Objective Aperture 32mm, Min. Focus: 0.2m (7.9in.) from end of telescope, 0.3m (1ft.) from instrument centre, Field of View 1°25’, Multiplication Constant 100, Additive Constant 0, Compensator Range +15’, Compensator Setting Accuracy +0.5”.
Including Standard Accessories: -
Toolkit (01 No.),
Operation Manual (01 No.),
Specifications:
32x Magnification, Accuracy ±2mm Image Erect, Effective Objective Aperture 32mm, Min. Focus: 0.2m (7.9in.) from end of telescope, 0.3m (1ft.) from instrument centre, Field of View 1°25’, Multiplication Constant 100, Additive Constant 0, Compensator Range +15’, Compensator Setting Accuracy +0.5”.
Products:
Having 32x Magnification, Accuracy ±2mm Image Erect, Effective Objective Aperture 32mm, Min. Focus: 0.2m (7.9in.) from end of telescope, 0.3m (1ft.) from instrument centre, Field of View 1°25’, Multiplication Constant 100, Additive Constant 0, Compensator Range +15’, Compensator Setting Accuracy +0.5”.
Including Standard Accessories: -
Toolkit (01 No.),
Operation Manual (01 No.),
With stand and staff 5 Mtr.
