theodolites integrate the same high-quality advanced absolute circle reading technology found in Topcon's high-performance total station products for more accurate field calculations. They continue to deliver the highest quality optics and electronics. The ET-202 series weathers any wet or dust conditions in the field, allowing for a more productive day during inclement weather. All models are compact and lightweight for easy portability and their simple operation provides precise measurement in a functional, hassle-free package.

FEATURES:

• Top quality
• Low cost
• Crisp LCD display
• Simple operation
• Simple back sight setting at the push of a button
• Degrees or percentage readings for the vertical angle

accessories: -

Battery Charger (01 No.)

Chargeable Battery (01 Nos.)

Operation Manual (01 No.)

Tool Kit (01 No.)

Carrying Case (01 No.)

Plum Bob (01 No.)

Aluminium Heavy-Duty Tripod (01 No.)

TELESCOPE :

• Length: 149mm
• Objective Lens: 45mm
• Magnification: 26x
• Image: Erect
• Field of View: 1°30'
• Resolving Power: 3"
• Minimum Focus: 90cm
• Stadia Constant: 0
• Sighting Collimator: Double

ELECTRONIC ANGLE MEASUREMENT :

• Method: Absolute Reading
• Detecting: Horizontal: 1 side, Vertical: 1 side
• Minimum Reading: 10"/20"
• Accuracy: 9", 7" and 5" models available
• Diameter of Circle: 71mm

DISPLAY :

• Display Panel: 1 Side, LCD 7 Segments
• Illumination: Display only

OPTICAL PLUMMET TELESCOPE :

• Magnification: 3X
• Field of View: 3°
• Focusing Range: 0.5m~

LEVEL SENSITIVITY :

• Plate Level: 60"/2mm
• Circular Level: 10'/2mm

WATER / DUST PROTECTION :

• Standard: IP-66

POWER SUPPLY :

• Battery: Four AA batteries (included)
• Operating Time: 170hrs on Four AA's

DT-200 Series Digital Theodolite
