The jaw crusher consists of a fixed jaw and a movable jaw, forming a V-shaped crushing chamber. The movable jaw moves back and forth, compressing and breaking the material against the fixed jaw. Material is fed into the top opening and is progressively crushed as it moves downward through the chamber. The size of the output material is determined by the adjustable gap between the jaws at the discharge point. This design allows for efficient size reduction with a typical crushing ratio between 6:1 and 8:1.

•  Compact and rugged for laboratory and small production units
•  Designed for speed crushing
•  Discharge opening adjustment range: 3 - 10mm
•  Manganese steel jaws adjustable up to 6 mm opening
•  250 kg materials can be crushed in approx. eight hours
•  Supported with strong steel frame
•  Voltage: 440 V, Three Phase A.C. Supply

• As per IS Standard.

•  Compact and rugged for laboratory and small production units
•  Designed for speed crushing
•  Discharge opening adjustment range: 3 - 10mm
•  Manganese steel jaws adjustable up to 6 mm opening
•  250 kg materials can be crushed in approx. eight hours
•  Supported with strong steel frame
•  Voltage: 440 V, Three Phase A.C. Supply
