A Gyratory Sieve Shaker is an advanced device designed for the precise grading of powders, granules, and other materials. It is widely utilized in industries such as chemical processing, pharmaceuticals, food and beverage, and construction materials testing.

• In addition to the Gyratory motion of the table, there is an upward and downward movement ensuring that each square inch of the sieve is utilized. The whole gear mechanism runs is an oil bath
• Robust construction
• Unmatched performance
• Long service life
• Easy installation

• As per IS Standard

Carries up to 7 sieves of 150- or 200-mm diameter. The shaker is driven by a 1/4 H.P. Motor through a reduction gear immersed in oil. The sieve table does not rotate but is inclined from the vertical axis and the direction on inclination charges progressively in clockwise direction.
If the stop pin below the table is removed, the shaker can have a rotary motion. In addition to this gyratory motion of the table, there is an upward and downward movement ensuring that each square cm of the sieve is utilized. A pair of rods and a holder can be fixed on the
top of the upper most sieve, and thus the sieve set in firmly held. Suitable for operation from 230 V 50 Hz, Single phase A.C. supply.

• Adopter for 300 mm Dia sieve available at extra cost
• Adopter for 450 mm Dia sieve available at extra cost
